Description
Model | PD570 PRO SDI |
---|---|
Max. Input Resolution | 1920×1080p@60/50fps |
Recording Mode | Software Compression, Real-Time Mode |
Interface | USB3.0 (SuperSpeed) UVC |
Dimension | 37x90mm |
Video Input | 1xSDI |
Video RAW Data Format | YUY2 |
Video Input Resolution | 1920×1080p@60/50fps 1920×1080p@30/25/24fps 1920×1080i@60/50fps 1280×720p@60/50fps 720×480i@60fps 720×576i@50fps |
Recording Video Format | YUY2 (USB3.0) |
UVC Video Output Resolution | 1920×1200p@60/50/30/25/24fps 1920×1080p@60/50/30/25/24fps 1280×1024p@60/50/30/25/24fps 1280×720p@60/50/30/25/24fps 1024×768p@60/50/30/25/24fps 800×600p@60/50/30/25/24fps 640×480p@60/50/30/25/24fps |
Audio Input | SDI Embedded Audio 3.5mm Analog Stereo Audio |
UAC Audio Output Format | Stereo / 16-bit / 48000Hz |
System Requirement | |
OS Support | Windows 7 / Windows 8 / Windows 8.1 Windows 10 ( 32-bit and 64-bit ) Linux / MAC OS / Android |
