Smart-VDO Edge 700 TOPS - VPP6N0 IGX

    For further assistance or to receive an offer for this product, please fill out the contact form below.

    Company/Organisation

    Your Name

    Your Email

    Country

    Product Name

    Market Application

    Your Message

    By clicking Send, you agree to our Terms and Data Use Policy.

    SKU: VPP6N0 IGX Categories: , Tags: , , ,

    Description

    System
    CPU NVIDIA® IGX Orin™
    12-core Arm® Cortex®-A78AE v8.2 64-Bit CPU 3MB L2 + 6MB L3
    GPU NVIDIA® IGX Orin™
    2048-Core NVIDIA Ampere Architecture GPU with 64 Tensor Cores

    NVIDIA® RTX A6000
    48 GB GDDR6 Memory, 768 GB/s Memory Bandwidth
    10752-Core NVIDIA Ampere Architecture GPU with 336 Tensor Cores
    AI Performance 700 TOPS
    System Memory 64GB LPDDR6
    Interface
    Storage 64GB eMMC 5.1 ( On NVIDIA IGX Orin™ Module)
    4×SATA
    Display Interface 4×DP1.4
    Ethernet 2×100Gb QSFP28 Port
    2×RJ45 for 10/100/1000Mbps Ethernet
    DHCP Client
    Expansion Slot PCIe:
    1×PCIe Gen5×16 Slot ( With 8 PCIe Lanes )
    1×PCIe Gen5×16 Slot ( With 16 PCIe Lanes, for Optional RTX A6000 )

    M.2:
    1×M.2 2230 E Key USB2.0/PCIe Gen2×1 Slot
    1×M.2 2280 M Key PCIe Gen4×4 Slot
    USB 4×USB3.2 Gen2 ( Type-A )
    4×USB3.2 Gen2 ( Pin Header )
    1×USB3.2 Gen2 ( Type-C )
    MIPI 16×MIPI CSI Lanes ( Support MIPI Camera, Capture Card )
    Audio 1×3.5mm Line In
    1×3.5mm Line Out
    1×3.5mm MIC in
    Peripherals 4×COM Port ( Pin Header )
    10×GPIO ( Pin Header )
    CAN Bus ( Pin Header )
    Misc. Features Firmware Upgradable
    GPU Support NVIDIA RTX A6000

    Additional information

    AI System

    NVIDIA® IGX Orin™

    Memory

    64GB LPDDR6

    AI Performance

    700 TOPS

    GPU Cores

    10752-Core Ampere, 2048-Core Ampere

    Tensor Cores

    336 Tensor Cores, 64 Tensor Cores
